A durable, weather‑resistant Mylar‑cone loudspeaker built around a robust ferrite magnet assembly and a square mounting bezel for secure installation. The combination of materials and construction gives this unit long‑term reliability in environments where conventional paper‑cone speakers would quickly degrade.

The Mylar diaphragm is fully impervious to moisture, making the speaker suitable for outdoor enclosures, exposed installations, and any application where humidity or intermittent water contact is expected. Its broad frequency response ensures clear audio reproduction for general signalling, voice prompts, and alarm sounders, while maintaining stable performance over time.

RoHS compliant.

Features:

  • Weatherproof Mylar cone — Moisture‑proof diaphragm for dependable outdoor and high‑humidity use.
  • Ferrite magnets — Stable magnetic assembly delivering consistent output and long service life.
  • Square mounting bezel — Secure, repeatable panel mounting for enclosures and equipment housings.
  • Wide frequency response — Clear reproduction suited to alarms, signals, and voice applications.
  • Outdoor‑ready construction — Materials selected to resist water, temperature changes, and general exposure.

Contents:

  • 1 x 10W 8 Ohm 100mm Square Mylar Cone Speaker.

Dimensions:

  • Length: 102.4mm (Nominal).
  • Width: 102.4mm (Nominal).
  • Height: 36.5mm.

Resources:

Documents & downloads

Technical Information

AttributeValue
Length 102.4mm (Nominal).
Width 102.4mm (Nominal).
Height 36.5mm.
Impedance 8 Ohms.
Resonance 230Hz.
Volume 93dB.
