Grove Beginner Kit for Arduino - All-in-one Arduino Compatible Board

Learn Arduino the easy way with the Grove beginners kit. Powered by an Arduino UNO compatible ATmega320p based Seeeduino Lotus board, this kit also contains 10 additional Grove Arduino sensors all joined together on a single board. Learning new things is always difficult, and it’s the same for Arduino beginners, but with this kit and it’s supporting guides you’ll have the most shallow learning curve possible.

Unlike most kits, the Grove Beginner Kit for Arduino is an all-in-one kit, no breadboard, no soldering, and even no wiring is needed. All the modules have been connected to the Seeeduino(Microcontroller) through the PCB stamp holes so no Grove cables are needed to connect. Allowing you to focus just on coding and Arduino Learning.

The kits mainboard also features Grove connectors and Arduino shield connectors. Further Grove modules can therefore be connected so the kit can grow as you do. Just connect the module to the shield with one of the six supplied Grove cables and get to work straight away. You can even pop out the modules supplied with this kit and use them with Grove cables instead, allowing you to build real-world projects not just theoretical ones.

Features:

• This kit has been designed as an entry-level kit that can also grow as you grow.
• It features an Arduino UNO compatible board(ATmega328p based Seeeduino Lotus) + 10 most commonly used Arduino modules.
• All modules are pre-wired, so, no breadboard, jumper cables, or even Grove cables required.
• With 12 step by step project tutorials provided, this is ideal for the beginner and also STEM/STEAM education.
• There is also a 74 page PDF Wiki.
• The kit is compatible with other Grove modules.
• There are 6 Grove cables supplied with the kit for use with any additional Grove modules or, if you would prefer to remove one of the supplied modules from the board and use it remotely you can do.

Contents:

• 1 x Grove Beginner Kit For Arduino Board.
• 1 x Micro USB Cable.
• 6 x Grove Cables.
• Included onboard:
• 1 x LED.
• 1 x Buzzer.
• 1 x OLED Display.
• 1 x Button.
• 1 x Rotary Potentiometer.
• 1 x Light Module.
• 1 x Sound Module.
• 1 x Temperature & Humidity Sensor.
• 1 x Air Pressure Sensor.
• 1 x 3-Axis Accelerator.
• 1 x Seeeduino Lotus ATmega320p based board.

Dimensions:

• Length: 175mm.
• Width: 105mm.

Video:

Resources:

• Grove Beginner Kit for Arduino Wiki [PDF].
• Grove Beginner Kit for Arduino Schematic Design Files.
• Sensor Datasheet.
• Initial Arduino Firmware Demo.
• Grove Beginner Kit For Arduino Resources in one(20200401)[7z].
• Grove Beginner Kit For Arduino FCC + SDOC Certificates.
